▸Orbital parameters

Orbit class	LEO
Inclination	34.9980°
Eccentricity	0.0003466
Period	94.5 min
Apogee	499 km
Perigee	494 km
Mean motion	15.23027369 rev/day
RAAN	72.8602°
Arg of perigee	226.9431°
Mean anomaly	133.0994°
B*	2.0890e-4
Rev at epoch	10,248

▸Two-line element set (TLE)

EPOCH Jul 7, 2026SOURCE CelesTrakDERIVED currentUPDATED Jul 7, 2026

1 60947U 24156C 26188.10578654 .00005003 00000-0 20890-3 0 9995

2 60947 34.9980 72.8602 0003466 226.9431 133.0994 15.23027369102484

▸ source OMM (JSON)

{
  "OBJECT_NAME": "YAOGAN-43 02C",
  "OBJECT_ID": "2024-156C",
  "EPOCH": "2026-07-07T02:32:19.957+00:00",
  "MEAN_MOTION": 15.23027369,
  "ECCENTRICITY": 0.0003466,
  "INCLINATION": 34.998,
  "RA_OF_ASC_NODE": 72.8602,
  "ARG_OF_PERICENTER": 226.9431,
  "MEAN_ANOMALY": 133.0994,
  "EPHEMERIS_TYPE": 0,
  "CLASSIFICATION_TYPE": "U",
  "NORAD_CAT_ID": 60947,
  "REV_AT_EPOCH": 10248,
  "BSTAR": 0.0002089,
  "MEAN_MOTION_DOT": 0.00005003,
  "MEAN_MOTION_DDOT": 0
}

Reconstructed from CelesTrak OMM mean-elements (element-set number is a placeholder). TLE/OMM data is approximate. Not for operational use or collision avoidance.

▸Satellite metadata

Name	YAOGAN-43 02C
Operator	General Armaments Dept. of the PLAHIGHvia GCAT — Jonathan McDowell's General Catalog
Country	China
Launch date	Sep 3, 2024HIGHvia GCAT — Jonathan McDowell's General Catalog
Launch mass (kg)	300HIGHvia GCAT — Jonathan McDowell's General Catalog
Mission purpose	—
Object class	PAYLOADHIGH

▸Data quality

Score85 / 100

Claims7

Sources1

TLEavailable

▸Sources

GCAT — Jonathan McDowell's General CatalogCC BY 4.0planet4589.org

▸Actions

GET /api/v1/satellites/60947

//Orbital data is approximate and not for operational use. Last ingested from CelesTrak on Jul 7, 2026.
