▸Orbital parameters

Orbit class	LEO
Inclination	34.9945°
Eccentricity	0.0001305
Period	94.9 min
Apogee	516 km
Perigee	515 km
Mean motion	15.16823317 rev/day
RAAN	318.4842°
Arg of perigee	188.3032°
Mean anomaly	171.7659°
B*	2.2641e-4
Rev at epoch	16,384

▸Two-line element set (TLE)

EPOCH Jul 6, 2026SOURCE CelesTrakDERIVED currentUPDATED Jul 7, 2026

1 57456U 23106E 26187.78980447 .00004523 00000-0 22641-3 0 9992

2 57456 34.9945 318.4842 0001305 188.3032 171.7659 15.16823317163842

▸ source OMM (JSON)

{
  "OBJECT_NAME": "YAOGAN-36 05C",
  "OBJECT_ID": "2023-106E",
  "EPOCH": "2026-07-06T18:57:19.106+00:00",
  "MEAN_MOTION": 15.16823317,
  "ECCENTRICITY": 0.0001305,
  "INCLINATION": 34.9945,
  "RA_OF_ASC_NODE": 318.4842,
  "ARG_OF_PERICENTER": 188.3032,
  "MEAN_ANOMALY": 171.7659,
  "EPHEMERIS_TYPE": 0,
  "CLASSIFICATION_TYPE": "U",
  "NORAD_CAT_ID": 57456,
  "REV_AT_EPOCH": 16384,
  "BSTAR": 0.00022641,
  "MEAN_MOTION_DOT": 0.00004523,
  "MEAN_MOTION_DDOT": 0
}

Reconstructed from CelesTrak OMM mean-elements (element-set number is a placeholder). TLE/OMM data is approximate. Not for operational use or collision avoidance.

▸Satellite metadata

Name	YAOGAN-36 05C
Operator	General Armaments Dept. of the PLAHIGHvia GCAT — Jonathan McDowell's General Catalog
Country	China
Launch date	Jul 26, 2023HIGHvia GCAT — Jonathan McDowell's General Catalog
Launch mass (kg)	300HIGHvia GCAT — Jonathan McDowell's General Catalog
Mission purpose	—
Object class	PAYLOADHIGH

▸Data quality

Score85 / 100

Claims7

Sources1

TLEavailable

▸Sources

GCAT — Jonathan McDowell's General CatalogCC BY 4.0planet4589.org

▸Actions

GET /api/v1/satellites/57456

//Orbital data is approximate and not for operational use. Last ingested from CelesTrak on Jul 7, 2026.
