▸Orbital parameters

Orbit class	SSO
Inclination	97.7757°
Eccentricity	0.0008775
Period	96.2 min
Apogee	583 km
Perigee	571 km
Mean motion	14.96715329 rev/day
RAAN	201.3605°
Arg of perigee	278.7997°
Mean anomaly	81.2230°
B*	1.3747e-4
Rev at epoch	37,302

▸Two-line element set (TLE)

EPOCH Jul 7, 2026SOURCE CelesTrakDERIVED currentUPDATED Jul 7, 2026

1 44520U 19058B 26188.17533575 .00001512 00000-0 13747-3 0 9993

2 44520 97.7757 201.3605 0008775 278.7997 81.2230 14.96715329373020

▸ source OMM (JSON)

{
  "OBJECT_NAME": "KX-09",
  "OBJECT_ID": "2019-058B",
  "EPOCH": "2026-07-07T04:12:29.009+00:00",
  "MEAN_MOTION": 14.96715329,
  "ECCENTRICITY": 0.0008775,
  "INCLINATION": 97.7757,
  "RA_OF_ASC_NODE": 201.3605,
  "ARG_OF_PERICENTER": 278.7997,
  "MEAN_ANOMALY": 81.223,
  "EPHEMERIS_TYPE": 0,
  "CLASSIFICATION_TYPE": "U",
  "NORAD_CAT_ID": 44520,
  "REV_AT_EPOCH": 37302,
  "BSTAR": 0.00013747,
  "MEAN_MOTION_DOT": 0.00001512,
  "MEAN_MOTION_DDOT": 0
}

Reconstructed from CelesTrak OMM mean-elements (element-set number is a placeholder). TLE/OMM data is approximate. Not for operational use or collision avoidance.

▸Satellite metadata

Name	KX-09
Operator	National Space Science CenterHIGHvia GCAT — Jonathan McDowell's General Catalog
Country	China
Launch date	Aug 30, 2019HIGHvia GCAT — Jonathan McDowell's General Catalog
Launch mass (kg)	100HIGHvia GCAT — Jonathan McDowell's General Catalog
Mission purpose	—
Object class	PAYLOADHIGH

▸Data quality

Score85 / 100

Claims7

Sources1

TLEavailable

▸Sources

GCAT — Jonathan McDowell's General CatalogCC BY 4.0planet4589.org

▸Actions

GET /api/v1/satellites/44520

//Orbital data is approximate and not for operational use. Last ingested from CelesTrak on Jul 7, 2026.
