▸Orbital parameters

Orbit class	SSO
Inclination	97.6217°
Eccentricity	0.0005456
Period	95.7 min
Apogee	557 km
Perigee	549 km
Mean motion	15.04562142 rev/day
RAAN	14.4070°
Arg of perigee	75.0046°
Mean anomaly	285.1784°
B*	1.6290e-4
Rev at epoch	70,683

▸Two-line element set (TLE)

EPOCH Jul 6, 2026SOURCE CelesTrakDERIVED currentUPDATED Jul 7, 2026

1 39227U 13042A 26187.98551816 .00002224 00000-0 16290-3 0 9991

2 39227 97.6217 14.4070 0005456 75.0046 285.1784 15.04562142706834

▸ source OMM (JSON)

{
  "OBJECT_NAME": "ARIRANG-5 (KOMPSAT-5)",
  "OBJECT_ID": "2013-042A",
  "EPOCH": "2026-07-06T23:39:08.769+00:00",
  "MEAN_MOTION": 15.04562142,
  "ECCENTRICITY": 0.0005456,
  "INCLINATION": 97.6217,
  "RA_OF_ASC_NODE": 14.407,
  "ARG_OF_PERICENTER": 75.0046,
  "MEAN_ANOMALY": 285.1784,
  "EPHEMERIS_TYPE": 0,
  "CLASSIFICATION_TYPE": "U",
  "NORAD_CAT_ID": 39227,
  "REV_AT_EPOCH": 70683,
  "BSTAR": 0.0001629,
  "MEAN_MOTION_DOT": 0.00002224,
  "MEAN_MOTION_DDOT": 0
}

Reconstructed from CelesTrak OMM mean-elements (element-set number is a placeholder). TLE/OMM data is approximate. Not for operational use or collision avoidance.

▸Satellite metadata

Name	ARIRANG-5 (KOMPSAT-5)
Operator	Korea Aerospace Research InstituteHIGHvia GCAT — Jonathan McDowell's General Catalog Korea Aerospace Research InstituteMEDIUMvia Wikidata
Country	South KoreaMEDIUMvia Wikidata
Launch date	Aug 22, 2013HIGHvia GCAT — Jonathan McDowell's General Catalog
Launch mass (kg)	1400HIGH

▸Data quality

Score90 / 100

Claims9

Sources2

TLEavailable

▸Sources

GCAT — Jonathan McDowell's General CatalogCC BY 4.0planet4589.org
WikidataCC0 1.0query.wikidata.org
